⚡ Flexible 1+N Scaling: Future-proof your energy needs with Flexible 1+N parallel operation, allowing you to expand capacity seamlessly as your business grows.
-
🏗️ Compact & Space-Efficient: Engineered for ease of installation, its compact design minimizes site occupation without compromising on power density.
-
☀️ Integrated DC Coupling: Features an optional DC coupling interface with independent MPPT and centralized management. Eliminate the cost and complexity of additional combiner boxes.
-
📱 Remote Intelligence: Stay in control 24/7 with 4G/WiFi monitoring. Our smart cloud platform enables remote inspections and diagnostics, significantly reducing manual maintenance costs.
-
💰 Automated Peak Shaving: Maximize savings through automated peak shaving and valley filling, fully controlled by our integrated BMS, PCS, and EMS synergy.
| Category | Parameter | Specification Details |
| 🔋 DC Battery | Cell Type | LFP 314Ah |
| Pack Configuration | 16.077kWh / 1P16S | |
| Capacity & Pack Quantity | 225kWh / 14 Packs | |
| Battery Voltage Range | 627V ~ 806V | |
| Cycle Life | 8000 Cycles (@70% SOH) | |
| Temperature Monitoring | 112 points | |
| ☀️ PV Side | Max. Input Power | 200kW |
| Max. Input Current | 320A | |
| ⚡ AC Side | AC Rated Power | 100kW |
| AC Maximum Power | 110kW | |
| System Voltage | 400V (360Vac ~ 440Vac) | |
| Power Factor | -1 ~ 1 | |
| ⚙️ System | Max. Efficiency | ≥ 89% |
| Operating Temp | -30°C ~ 55°C (Derating >40°C) | |
| Dimensions (WDH) | 1050 × 1050 × 2350 mm | |
| Weight | 2100 kg | |
| IP Grade | IP54 (Complete Machine) | |
| Connectivity | 4G / WiFi |
